Sprocket segments are easily replaced without any special tooling. Segments eliminate the risk of Rim misalignment. Thus, reducing maintenance and downtime expense. These segments simplify field replacements and result in worthwhile cost reduction.

Brand Part No. Ref No. Part No. Model Description (kg)
CATERPILLAR 4I7337   E110B,E120B,311,312 Idler Group 90.00
CR5732 7Y1601,1132907 E200B,EL200B,315,318,320 Idler Group 135.00
094-1384   E240,E240B, -C Idler Group 120.00
4C2084 CR5127 225- 6.91"7.50"PITCH Idler Group 160.00
4E8500 CR5132 235 Idler Group 270.00
CR5786 115-6337 322B Idler Group 132.00
CR5884 1028155 325 Idler Group 170.00
CR6087 1028152, 7Y0762 330 Idler Group 240.00
CR6597 1156366 345 Idler Group 255.00
CR6403 1358903 350 Idler Group 270.00
136-2429   365 Idler Group 525.00
194-1157 135-8904 375,385 Idler Group 590.00
960253   E300B Idler Group 198.00
8J6562 2T0048,2154459 615/623 Bottom Idler Idler Group 77.00
3G1086 2154458,2T0047 615/623 Center Idler Idler Group 40.00
2T0046 3G7490 615/623 Upper roller Roller Group 18.00
1447321, 8W4731 3G0897, 3J4778 631-657 Floor roller Roller Group 21.00
9J1035   633C,D BOTTOM IDLER Idler Group 80.00
CR3004 9N4173 D3B,C,G/D4B,C,G Idler Group 110.00
CR5420   D5C-D5G Idler Group 175.00
CR3189WB 7P9017 953 Idler Group 180.00
CR3189 7T3501 WS3 D5B W/O BRACKETS Idler Group less bracket 135.00
CR4007WB 7P2719 963 Idler Group 195.00
CR4587 190-1534 D4H (475mm) Idler Group 81.00
CR4585 190-1551 D4H (500mm) Idler Group 90.00
CR4589 190-1546 D5H,D6M Idler Group 112.00
CR4094 6L9210 D6D with brackets Idler Group 170.00
8E4007   D5H, 517 Skidder Idler Group 160.00
CR4909 151-4587 D6H,D6R (545mm) Idler Group 147.00
CR4616 6T3216 D6H,D6R (570mm) Idler Group 159.00
CR4911 135-9896, 6Y2031 D7H, D7R (585mm) Idler Group 240.00
CR4593 192-0216 D7H,D7R (628mm) Idler Group 260.00
CR4096 6L9212 D8H,K W/ BRACKETS Idler Group 329.00
CR4531 111-1729 D8N/R/T (620mm)- rear Idler Group 300.00
244-1324   D8N/R/T rear with Landfill guarding Idler Group 300.00
CR4530 111-1730 D8N/R/T (698mm)- front Idler Group 350.00
244-1323   D8N/R/T- front with Landfill guarding Idler Group 350.00
CR4681 125-4655 D9N/R/T Idler Group 450.00
167-1947   D9N/R/T with Landfill guarding Idler Group 450.00
125-3537 9W9734 D10N/R/T Idler Group 590.00
156-0313 9W9650 D11N/R/T Idler Shell Idler Shell 930.00
CASE CA0693   450C Idler Group 85.00
CA0620   850B Idler Group 110.00
CA0757   1150D/E/G Idler Group 140.00
HITACHI 9101919   EX30 Idler Group 52.00
9068477   EX60-1 Idler Group 60.00
9097575   EX60-3 Idler Group 57.00
9068144   EX100,EX120-1,-2 Idler Group 85.00
9092973 AT180421 EX100-2,EX120-2,JD490E Idler Group 85.00
9069635   EX150, 490D, 590D Idler Group 105.00
9071453   EX100M Idler Group 135.00
9147610   EX100M-5 Idler Group 135.00
9066393 9143400 EX200, EX200-1 Idler Group 130.00
9145269 SI0738 EX200-2,3,5 Idler Group 125.00
9115208 SI0824 EX270, EX300-1, EX320 Idler Group 154.00
9154690 9933956 EX300-5 Idler Group 185.00
9074011 9134295, 9134152 EX400LC, EX400-2,3, 992D Idler Group 230.00
9137270   EX550 Idler Group 277.27
9134272   EX700,750-5 Idler Group 360.45
9101204   EX1100 Idler Group 641.36
TIMBERJACK KO76, KO156 F121365 466E,566.666E, TJ 618,628,2628, Idler Group 240.00
KOMATSU 201-30-00012   PC60-5 Idler Group 65.00
203-30-00133   PC100-5, 120-5,6 Idler Group 80.00
205-30-00182 KM1641 PC180-2, 200-3 Idler Group 130.00
20Y-30-00030 KM1642 PC200-5, 220-5 Idler Group 130.00
20Y-30-00321 KM3299 PC220-7,8, PC228 Idler Group 130.00
207-30-00071   PC300-1,2,3 Idler Group 190.00
207-30-00160 KM2018, KM1927 PC300, 280-3, 300-5 Idler Group 190.00
208-30-00070   PC400-3 Idler Group 290.00
208-30-00200 KM1973 PC400-5, PC400 Idler Group 290.00
101-30-61210X KM0914 D20 Idler Group 65.00
113-27-31320 KM0840 D31-17, D30, D37 Idler Group 90.00
128-04-0H92 IN3810 D39 Idler Group 150.00
124-30-00102 124-30-00103 D39E,P-21 D41E,P-6 Early S/N Idler Group 124.00
124-30-00105 124-30-00106 D41E,P-6 Late S/N Idler Group 160.00
134-30-00201 KM6100 D61E,P Idler Group 228.00
  144-30-00038 KM834 D65 Idler Group 210.00
14X-30-00112 KM2107 D65-12, D85SS-2, D85ESS-12 Idler Group 195.00
17A-30-00040 KM836 D155 Idler Group 474.00
195-30-00283 KM837 D355 Idler Group 650.00
KOBELCO 24100N6296F1 YT52D00002F1 SK60-3 Idler Group 60.00
LP52D00003F2 24100N6504F1 SK100 Idler Group 110.00
24100N5948F4 24100N5948F2 SK200-3, SK200-5 Idler Group 125.00
24100J4064F1 24100N4064F1 SK07N2, K907-III YUTANI MD200B Idler Group 145.00
24100J6379F1   SK09N2 Idler Group 150.00
24100J11697F1   SK220, SK250 Idler Group 150.00
24100N3099F5 LC52DU0000F1 SK300 Idler Group 230.00
LC52D00002F1   SK330 Acera Idler Group 205.00
SUMITOMO KRA1767Z-C   SH200-3 Idler Group 120.00
LINKBELT KRA0946   LS2800LC-II Idler Group 110.00
JOHN DEERE ID0536   450G Idler Group 107.00
ID0794 ID1558 650G Idler Group 154.00
ID0609 AT47057 690B,C,D Idler Group 110.00
ID0892   690E Idler Group 125.00
ID1820 AT210558 450H Idler Group 105.00
ID1821 AT211283 650H Idler Group 140.00
ID1560 ID1561 650G Idler Group 144.00
ID2164   700H Idler Group 144.00
ID1453   750B Idler Group 186.00
AT304377 AT305549 750J Idler Group 195.00
AT305808  กก 850J Idler Group 240.00
DAEWOO
DOOSAN
2270-1064P? 2270-1108 S220LC-3 / S220-5 Idler Group 130.00
2270-1028P   S280LC / S280LC-3 Idler Group 180.00
2270-9405E   S400LC-V / S450LC-3 Idler Group 260.00
VOLVO
SAMSUNG
1081-04000 1081-04140 SE130LC/ SE130LC-2 Idler Group 130.00
1081-00980  กก SE210 / MX8 / MX8-2? Idler Group 130.00
1081-00310 1081-03790 SE210LC, MX8-2 Idler Group 150.00
1181-00030   EC210 Idler Group 150.00
1181-00721   EC290 Idler Group 190.00
LH495 1081-03910 SE280-2, EC330B. EC360 Idler Group 250.00
1081-02232 1451-0975 EC460 / SE450 Idler Group 250.00
HYUNDAI 81N4-13010   R130LC-7 Idler Group 110.00
81EM-14101   R210LC-3 Idler Group 125.00
81N6-13010   R210LC-5 Idler Group 125.00
81E9-2004   R290LC-3, R290LC, R320LC Idler Group 195.00
81N8-13010   R290LC-7 Idler Group 195.00
81E7-01030   R4500 Idler Group 250.00
ETC LH485   808HDLC Idler Group 170.00
FA6C   FL6A Idler w/recoil&tensioner 141.00
FA6CHD   FL6B Idler w/recoil&tensioner 177.00
TM2   FL4 Idler w/recoil&tensioner 75.00
AT16   D4 Idler w/recoil&tensioner 194.00
FT2764HD   D5 Idler w/recoil&tensioner 320.00
